Dimensions and Specifications
Cable Size Range
1500-2500 kcmil
Expanded Inner Diameter
4.5 in
Expanded Inner Diameter (Metric)
114.3 mm
Inner Diameter After Shrink (Imperial)
1.5 in
Inner Diameter After Shrink (Metric)
3.81 cm²
Inner Diameter Before Shrink (Imperial)
4.5 in
Inner Diameter Before Shrink (Metric)
11.43 cm²
Maximum Conductor Size (Imperial)
2500 kcmil
Maximum Conductor Size (Metric)
1267 mm²
Maximum Operating Temperature (Celsius)
100 Degree Celsius
Maximum Operating Temperature (Fahrenheit)
230 Degree Fahrenheit
Maximum Voltage Rating
1 kV
Minimum Conductor Size (Imperial)
1500 kcmil
Minimum Conductor Size (Metric)
760.1 mm²
Minimum Shrink Temperature (Celsius)
121 Degree Celsius
Minimum Shrink Temperature (Fahrenheit)
250 °F
Operating Temperature (Celsius)
-55 to 100 Degrees Celsius
Operating Temperature (Fahrenheit)
-67 °F to 230 °F
Operating Temperature Range (Celsius)
-55 °C to -100 °C
Operating Temperature Range (Fahrenheit)
-67 °F to 230 °F
Overall Length (Imperial)
48 in
Overall Length (Metric)
1219 mm
Recovered Inner Diameter
1.5 in
Recovered Inner Diameter (Metric)
38.1 mm
Tensile Strength (Imperial)
2400 Pound-Force Per Square Inch
Voltage
1 kV
Voltage Rating
UL Rated to 600 V (Shall not exceed 1 kV)
Maximum Conductor Size Imperial
2500 kcmil
Maximum Conductor Size Metric
1267 mm²
Minimum Conductor Size Imperial
1500 kcmil
Minimum Conductor Size Metric
760.1 mm²
Minimum Shrink Temperature Fahrenheit
250 °F
Operating Temperature Celsius
-55 to 100 Degrees Celsius
Overall Length Imperial
48.0
Width
11.37 in
28.89 cm
Height
14.37 in
36.51 cm
Length
50.75 in
128.91 cm
Volume
135.98 dm3
Weight
14.78 lb
6.7 kg
