Dimensions and Specifications
Cable Size Range
12-6 AWG
Expanded Inner Diameter
0.4 in
Expanded Inner Diameter (Metric)
10.2 mm
Inner Diameter After Shrink (Imperial)
0.15 in
Inner Diameter After Shrink (Metric)
3.8 mm
Inner Diameter Before Shrink (Imperial)
0.4 in
Inner Diameter Before Shrink (Metric)
10.2 mm
Maximum Conductor Size (Imperial)
6 AWG
Maximum Conductor Size (Metric)
16 mm²
Maximum Operating Temperature (Celsius)
100 Degree Celsius
Maximum Operating Temperature (Fahrenheit)
230 Degree Fahrenheit
Minimum Conductor Size (Imperial)
12 AWG
Minimum Conductor Size (Metric)
4 mm²
Minimum Shrink Temperature (Celsius)
121 Degree Celsius
Minimum Shrink Temperature (Fahrenheit)
250 °F
Operating Temperature (Celsius)
-55 to 100 Degrees Celsius
Operating Temperature (Fahrenheit)
-67 °F to 230 °F
Operating Temperature Range (Celsius)
-55 °C to -100 °C
Operating Temperature Range (Fahrenheit)
-67 °F to 230 °F
Overall Length (Imperial)
48 in
Overall Length (Metric)
1.22 m
Recovered Inner Diameter
0.15 in
Recovered Inner Diameter (Metric)
3.8 mm
Relaxed Tube Length (Metric)
1 m
Tensile Strength (Imperial)
2400 Pound-Force Per Square Inch
UL Bug Temperature (Celsius)
125 Degrees Celsius
UL Bug Temperature (Fahrenheit)
257 Degrees Fahrenheit
UL Bug Voltage
600 Volt
Voltage Rating
1 kV
Maximum Conductor Size Imperial
6 AWG
Maximum Conductor Size Metric
16 mm²
Minimum Conductor Size Imperial
12 AWG
Minimum Conductor Size Metric
4 mm²
Minimum Shrink Temperature Fahrenheit
250 °F
Operating Temperature Celsius
-55 to 100 Degrees Celsius
Overall Length Imperial
48.0
Width
3.38 in
8.57 cm
Height
3.38 in
8.57 cm
Length
51.13 in
129.86 cm
Volume
582.42 cubic inch
9544.09 cm3
Weight
56.8 oz
1610.25 g
