Dimensions and Specifications
Barrel Inside Diameter
0.135 Inch
Barrel Length (Imperial)
0.25 Inch
Maximum Conductor Size (Imperial)
10 AWG
Maximum Conductor Size (Metric)
5.26 mm²
Maximum Insulation Outer Diameter (Imperial)
0.25 in
Minimum Conductor Size (Imperial)
12 AWG
Minimum Conductor Size (Metric)
3.31 mm²
Overall Length (Imperial)
1.03 in
Overall Width (Imperial)
0.38 in
Stud Size
#10
Barrel Length Imperial
0.25 Inch
Maximum Conductor Size Imperial
10 AWG
Maximum Conductor Size Metric
5.26 mm²
Minimum Conductor Size Imperial
12 AWG
Minimum Conductor Size Metric
3.31 mm²
Overall Length Imperial
1.03
