3M Cable Tie CT36BK175-L

3M Cable Tie CT36BK175-L

by 3M
No reviews
$685.99 - $685.99
$685.99
$685.99 - $685.99
$685.99
Free shipping
Extended Handling May Be Required
When you need strong cable ties that will hold up under any conditions without slipping, choose the 3M Nylon 6/6 Heavy-Duty Cable Tie. Each tie comes prepared to withstand the elements with a nylon composition... Read more
Please allow 2 days for production.

Overview

3M

3M Cable Tie CT36BK175-L

When you need strong cable ties that will hold up under any conditions without slipping, choose the 3M Nylon 6/6 Heavy-Duty Cable Tie. Each tie comes prepared to withstand the elements with a nylon composition of 6/6, and can withstand temperatures of 32 to 185 degrees F (0 to 85 degrees C). Curved tips on the end of the tie make it easier for you to thread and install quickly.3M™ Standard Nylon Cable Ties are available in several tensile strengths ranging from 18 lb. to 175 lb. and multiple lengths ranging from 4 inches to 48 inches to cover your needs. They are offered in natural and red for indoor use and UV weather-resistant black for indoor and outdoor use. UL Listed 62275 Type 21 or 21S and Plenum Rated AH-2 for use in air handling spaces. Made in the USA.
  • Secure wire bundles and harness components quickly, without slipping
  • Curved tip allows for faster threading and installation
  • Made in the USA
  • UL Listed 62275 Type 21 or 21S and Plenum Rated AH-2 for use in air handling spaces

Product Details

General Information
Brand
3M™
Cable Tie Type
Heavy Duty
Product Type
Cable Ties
Type
Standard
Country Of Origin
United States
Lead Time
2 days
California Residents
Proposition 65 Warning
Dimensions and Specifications
Approximate Length
36
Cable Diameter Range
8,1 - 39,4 mm
Cable Length (Imperial)
36 in
Cable Length (Metric)
914.4 mm
Cable Tie Base Height
36 in
Cable Tie Length
914 mm
Maximum Bundle Diameter
11 Inch
Maximum Bundle Diameter (Metric)
279 mm
Maximum Insulation Outer Diameter (Metric)
3.7 mm
Maximum Insulation Outside Diameter
0.145 in
Maximum Operating Temperature
85 Degree Celsius
Maximum Operating Temperature (Celsius)
85 Degree Celsius
Maximum Operating Temperature (Fahrenheit)
185 Degree Fahrenheit
Maximum Recommended Voltage Rating
600 V
Minimum Bundle Diameter
1.5 Inch
Minimum Bundle Diameter (Metric)
8.1 mm
Minimum Installation Temperature (Celsius)
0 Degree Celsius
Minimum Installation Temperature (Fahrenheit)
32 Degree Fahrenheit
Minimum Operating Temperature (Celsius)
-40 Degree Celsius
Minimum Operating Temperature (Fahrenheit)
-40 Degree Fahrenheit
Operating Temperature (Celsius)
85 Degree Celsius
Operating Temperature (Fahrenheit)
185 Degree Fahrenheit
Operating Temperature Range (Celsius)
0 °C to 85 °C
Operating Temperature Range (Fahrenheit)
32 °F to 185 °F
Overall Length (Imperial)
36 in
Overall Length (Metric)
914 mm
Overall Width (Imperial)
0.335 in
Overall Width (Metric)
8.5 mm
Tensile Strength (Imperial)
175 lbs
Tensile Strength (Metric)
79.38 kg
Maximum Insulation Outer Diameter Metric
3.7
Operating Temperature Celsius
85 Degree Celsius
Other Details
Cable Management Products
Cable Ties
Mil Spec
MS3367-12-0
Package Quantity
50
Plenum Rated
Yes
Solution For
Long-haul/Metro Loop Network: Outdoor
UV Resistant
Yes
Units Per Case
500.0
Units Per Bag
50
Tensile Strength Imperial
175 lbs
Material and Composition
Material
Nylon 6/6
Color and Appearance
Product Color
Black
Certifications and Standards
Flammability Rating
UL 94 V-2
UL Approval
Yes
