Athena Power AP-U1ATX30P8 20+4Pin Single 1U IPC Server Power Supply - 80PLUS bronze - OEM

$68.99
Free shipping
Athena Computer Power Corp’s AP-U1ATX30P8 is one of their recently revamped power supplies for IPC use. This server power supply now includes the Active PFC function and is rated at 80PLUS bronze certified efficiency. Equipped... Read more

Overview

Brand img

Athena Power AP-U1ATX30P8 20+4Pin Single 1U IPC Server Power Supply - 80PLUS bronze - OEM

Athena Computer Power Corp’s AP-U1ATX30P8 is one of their recently revamped power supplies for IPC use. This server power supply now includes the Active PFC function and is rated at 80PLUS bronze certified efficiency. Equipped with dual 40mm ball-bearing fans strategically placed on the rear and front of the power supply, exhaust generated heat from the core of the server/system. This smart auto fan controller will detect heat levels within the server/system and adjust the fan rotation accordingly, helping reduce energy use and noise levels. Maintaining their policy of “True Green Power” Athena Power has brought efficiency to their 1U server line. Active PFC and Full Range Input The Active PFC and Full Range function provides a smarter PSU. Able to detect the differences of wattage that is needed to power up your system, you can be rest assured as it will provide and maintain the most suitable power needed. Dual Fan With its dual fan features located at the front and back of the power supply, the rear fan intakes the heat that is produced inside the system and pushes it through the front fan. This design allows the power supply to be able to take 100% of the heat that is generated by the interior system and pushes it out of the server/system. While some other PSU fans work differently, this dual fan design is targeted to maintain a reliable source of power and keeping the system cool. Some may second guess this dual fan feature because it will increase noise volumes, but with its thermal fan speed control it will detect the amount of heat generated by the computer and spin accordingly. Smart Auto Fan Speed Controller Thermal fan speed control will detect the amount of heat generated by the computer. Using the speed controller to detect heat levels, it will automatically adjust the fan speed accordingly and the need to worry about heat levels, of a PSU, becomes almost non-existent. 80PLUS Certification Saving energy has become an important factor when choosing the appropriate power supply. 1U 300 Watt is one of the latest 1U PSU’s that brandishes 80PLUS Bronze certification. Providing efficiency during max and low loads, this PSU lives up to the standards of today’s world.

Product Details

General Information
Manufacturer
Athena Power
Part Number
AP-U1ATX30P8
Product Type
Power Supply
Power Description
Input Voltage Type
AC
Input Voltage
88 ~ 264 Volts AC
Output Voltage
+5V@13A, +12V1@14A, +12V2@14A, -12V@0.5A, +3.3V@13A, +5V_SB@2.5A, -5V@0.5A
Output Power
300 Watts
Physical Characteristics
Height
1.59"
Width
3.94"
Weight (Approximate)
1.70 lbs
Interfaces Ports
Connectors
ATX Connector 24 (20+4) Pin x 1
P4-12V 4 Pin x 1
PCIE 6 Pin x 1
SATA 15 Pin x 3
Molex 4 Pin x 2
Floppy 4 Pin x 1
