Athena Power AP-U1ATX40P8 1U EPS-12V/P4-ATX v2.2 400W IPC 80 Plus

No reviews
Original price $118.99 - Original price $118.99
Original price
$118.99
$118.99 - $118.99
Current price $118.99
Free shipping
Introducing Athena Power's 400W 1U (AP-U1ATX40P8) power supply. Designed for the 1U form factor, the 400 Watt 1U PSU provides a compact fit alongside flexibility for small industrial computer rackmounts. The EPS-12V 8pin and the... Read more

Overview

Athena Power

Athena Power AP-U1ATX40P8 1U EPS-12V/P4-ATX v2.2 400W IPC 80 Plus

Introducing Athena Power's 400W 1U (AP-U1ATX40P8) power supply. Designed for the 1U form factor, the 400 Watt 1U PSU provides a compact fit alongside flexibility for small industrial computer rackmounts. The EPS-12V 8pin and the addtional P4 4+4 pin connector gives full support for core 2 dual processors. The U1ATX40 also includes the Active PFC (Power Factor Correction) and remote ON/OFF function for high efficiency and reliability. With its internal front and rear 40mm ball-bearing fan and thermal fan speed control, allow this PSU to handle heavy server loads. Multiple Support Function Supporting ATX V2.3, EPS-12V Xeon, and i7 motherboards it also includes 2x PCI-E 6-pin connectors for advanced graphics cards running in quad SLI or Crossfire configuration. This PSU can be used for mini-servers, server assemblies, rackmount servers, and desktops. Active PFC and Full Range Input The Active PFC and Full Range function provides a smarter PSU. Able to detect the differences of wattage that is needed to power up your system, you can be rest assured as it will provide and maintain the most suitable power needed. Dual Fan With its dual fan features located at the front and back of the power supply, the rear fan intakes the heat that is produced inside the system and pushes it through the front fan. This design allows the power supply to be able to take 100% of the heat that is generated by the interior system and pushes it out of the server/system. While some other PSU fans work differently, this dual fan design is targeted to maintain a reliable source of power and keeping the system cool. Some may second guess this dual fan feature because it will increase noise volumes, but with its thermal fan speed control it will detect the amount of heat generated by the computer and spin accordingly. Smart Auto Fan Speed Controller Thermal fan speed control will detect the amount of heat generated by the computer. Using the speed controller to detect heat levels, it will automatically adjust the fan speed accordingly and the need to worry about heat levels, of a PSU, becomes almost non-existent. 80PLUS Certification Saving energy has become an important factor when choosing the appropriate power supply. 1U 400 Watt is one of the latest 1U PSU’s that brandishes 80PLUS Bronze certification. Providing efficiency during max and low loads, this PSU lives up to the standards of today’s world.

Product Details

General Information
Manufacturer
Athena Power
Part Number
AP-U1ATX40P8
Product Type
Power Supply
California Residents
Power Description
Input Voltage Type
AC
Input Voltage
88 ~ 264 Volts AC
Output Voltage
+5V@16A, +12V1@11A, +12V2@11A, -12V@0.8A, +3.3V@16A, +5V_SB@3A
Output Power
300 Watts
Physical Characteristics
Height
1.55"
Width
3.94"
Weight (Approximate)
3 lbs
Interfaces Ports
Connectors
ATX Connector 24 (20+4) Pin x 1
EPS 12V 8 (4 + 4) Pin x 1
P4-12V 4 Pin x 1
PCIE 6 Pin x 2
SATA 15 Pin x 3
Molex 4 Pin x 2
Floppy 4 Pin x 1
