Velleman LCR45 LCR and Impedance Meter, 1 Grade to 12 Grade

No reviews
Original price $134.99 - Original price $134.99
Original price
$134.99
$134.99 - $134.99
Current price $134.99
Free shipping
Features supplied with removable, gold-plated hook probes fluid measurements with hold function automatic or manual component type automatic or manual test frequency, DC, 1 kHz,15 kHz or 200 kHz enhanced measurement resolution: 0.2 µH, 0.2... Read more

Overview

Velleman

Velleman LCR45 LCR and Impedance Meter, 1 Grade to 12 Grade

Features

  • supplied with removable, gold-plated hook probes
  • fluid measurements with hold function
  • automatic or manual component type
  • automatic or manual test frequency, DC, 1 kHz,15 kHz or 200 kHz
  • enhanced measurement resolution: 0.2 µH, 0.2 pF and 0.2 Ohm
  • easy menu system for user settings
  • enhanced compensation for component parasitics and losses (such as core losses, etc.)
  • automatic or manual power-off

Specifications

  • resistance:
    • range: 0 Ohm to 2 MOhm
    • resolution: 0.1 Ohm
    • accuracy: ± 1.0 % ± 0.6 Ohm
  • capacitance :
    • range: 0.5 pF to 10000 µF
    • resolution: 0.2 pF
    • accuracy: ± 1.5 % ± 0.6 pF
  • inductance:
    • range: 1 µH to 10 H
    • resolution: 0.2 µH
    • accuracy: ± 1.5 % ± 0.6 µH
  • passive component impedance:
    • Re & Im: ± 1.5 % ± 10 LSD
    • magnitude: ± 1.5 % ± 10 LSD
    • phase: ± 5 %
  • measurement sample rate: 0.5 Hz to 2 Hz
  • peak test voltage (across O/C): -1.05 V to 1.05 V
  • peak test current: -3.25 mA to 3.25 mA
  • test frequency accuracy:
    • 1 kHz: ± 0.5 %
    • 14.9254 kHz: ± 0.5 %
    • 200 kHz: ± 0.5 %
  • sine purity: +60 dB 3rd harmonic
  • operating temperature range: 10° C to 40° C / 50° F to 104° F
  • battery operating voltage: 8.5 V to 13 V

Product Details

General Information
Manufacturer
Velleman
Part Number
LCR45
Product Type
LCR and Impedance Meter
