Details
Features
Laser Features:
Self-leveling cross-line laser with plumb dots for horizontal and vertical applications
GREENBEAM technology for bright, razor-sharp lines up to 130 ft (40 m)
High-performance diodes provide extended vertical line coverage
Manual mode allows positioning at any angle with pendulum lock
Pulse-modulated lines compatible with line receivers
Long runtime up to 20 hours with 12V Li-Power battery
Fast recharge time of approximately 45 minutes
Shock-absorbing protective housing with soft grip and protective sliders
Removable base for working over tracks and base plates
Multiple mounting options including 1/4 in thread, magnets, and wall bracket
Receiver Features:
Detects pulse-modulated laser lines (green or red) over long distances
Dual-sided illuminated digital display for easy reading
Visual arrow indicators for precise alignment
Adjustable acoustic signals with volume control (loud and quiet modes)
Two sensitivity settings: Fine (±1/32 in) and Coarse (±1/8 in)
Waterproof and dustproof with IP66 rating
Integrated magnet system and mounting bracket for versatile use
Battery status indicator
Up to 45 hours operating time
Size
Technical Data:
Laser Type: Cross-line with Plumb Dots
Working Range: Up to 130 ft (40 m)
Battery Type: 12V Li-Power 2.0 Ah
Runtime: Up to 20 Hours
Charging Time: Approx. 45 minutes
Receiver Sensitivity: ±1/32 in (Fine), ±1/8 in (Coarse)
Receiver Protection Rating: IP66
Receiver Line Height: 3-1/2 in (90 mm)
Receiver Runtime: Up to 45 hours
Self-Levelling Range: +/- 5°
Levelling Accuracy: +/- 18 in at 30 ft
Laser Wavelength: 510 - 530 nm
Measuring Range of Visible Line: 330' with Receiver
Laser Class: 2
