Features
High contrast LCD : 64 x 128 pixels with white LED backlight
Maximum sample rate : 1MS/s for repetitive signals, 100kS/s in real time
Input amplifier bandwidth : 200kHz (-3 dB)
Measurements can be performed up to : 100kHz
Input impedance : 100kohm // 20pF
high contrast LCD: 64 x 128 pixels with white LED backlight
maximum sample rate: 1MS/s for repetitive signals, 100kS/s in real time
input amplifier bandwidth: 200kHz (-3 dB)
measurements can be performed up to: 100kHz
input impedance: 100kohm // 20pF
maximum input voltage: 30Vpeak (AC + DC)
input coupling: DC and AC
AD resolution: 8 bits
run modes: run, single
trigger level adjustable: in 16 steps
timebase range: in 15 steps, 10µs/division to 500ms/division
input sensitivity range: in 6 steps, 100mV/division to 5V/division
test output: 1.95kHz / 3.3Vpp
full auto set up for: Volt/div and time/div (or manual)
sensitivity down to 10mV
readouts : DC, AC+DC, true RMS, dBm, Vpp, min. & max.
time and voltage markers readout
frequency readout (through markers)
battery operated : 4 x AAA batteries (max. 100mA)
power save mode
dimensions : 80 x 115 x 40 mm / 3.14 x 4.52 x 1.57"
weight: 190g (6.70 oz) with batteries
