3M™ 7100163522 Non-Insulated Brazed Seam Block Fork Terminal, BS-31-6-W

by 3M
$90.99
1000 pieces, made to order    Non-insulated, brazed-seam barrel ensures a secure fit and offers reliable performance    Beveled mouth offers easy insertion of wires    Suitable for use in a terminal block    Electrolytic... Read more

Overview

Brand img

3M™ 7100163522 Non-Insulated Brazed Seam Block Fork Terminal, BS-31-6-W

  • 3M
  • 7100163522

1000 pieces, made to order

    Non-insulated, brazed-seam barrel ensures a secure fit and offers reliable performance

    Beveled mouth offers easy insertion of wires

    Suitable for use in a terminal block

    Electrolytic copper construction offers good conductivity

    Withstands a maximum temperature of 347 degrees F (175 degrees C) for bare terminals

    600V-rated for building wire and 1000V for signs, fixtures or luminaires

    UL Listed, CSA Certified and RoHS 2011/65/EU Compliant

3M™ Block Fork Terminal ensures an ideal fit while offering reliable and safe performance. The non-insulated, brazed-seam barrel has a beveled mouth that guides the wire into position, and it withstands temperatures of 347 degrees F (175 degrees C). Electrolytic copper construction offers good conductivity and a tin-plated finish resists corrosion.

3M™ Block Fork Terminal withstands crimping pressures or operating stresses, and the sides of the terminal lie flat against the barrier portion of the terminal block to provide electrical contacts. UL Listed, CSA Certified and RoHS 2011/65/EU Compliant.


Product Details

General Information
Manufacturer
3M
Part Number
7100163522
Product Type
Crimp Terminals, Lugs & Wire Nuts
