Dimensions and Specifications
Conductor Sizes (Imperial)
16 AWG
Insulation Outside Diameter Range
0.50 - 1.00 Inch
Insulation Outside Diameter Range (Metric)
12.7-25.4 mm
Maximum Conductor Size (Imperial)
10 AWG
Maximum Conductor Size (Metric)
6 mm²
Maximum Insulation Outer Diameter (Imperial)
1 in
Maximum Insulation Outer Diameter (Metric)
25.4 mm
Minimum Conductor Size (Imperial)
22 AWG
Minimum Conductor Size (Metric)
.34 mm²
Minimum Insulation Outer Diameter (Imperial)
0.5 in
Minimum Insulation Outer Diameter (Metric)
12.7 mm
Molded Body Length
10.438 in
Molded Body Length (Metric)
268.3 mm
Voltage
1 kV
Maximum Conductor Size Imperial
10 AWG
Maximum Conductor Size Metric
6 mm²
Maximum Insulation Outer Diameter Metric
25.4
Minimum Conductor Size Imperial
22 AWG
Minimum Conductor Size Metric
.34 mm²
