3M™ Scotchlok™ Male Disconnect, Heat Shrink Fully Nylon Insulated Butted Seam

by 3M
Original price $155.99 - Original price $155.99
Original price
$155.99
$155.99 - $155.99
Current price $155.99
Free shipping
250 pieces    Butted-seam terminal uses blue pre-insulated, heat shrink tubing and ensures a secure fit while offering reliable performance    This male disconnect terminal offers excellent holding force    When crimped and shrunk, pre-insulated... Read more

Overview

Brand img

3M™ Scotchlok™ Male Disconnect, Heat Shrink Fully Nylon Insulated Butted Seam

  • 3M
  • 7100164279

250 pieces

    Butted-seam terminal uses blue pre-insulated, heat shrink tubing and ensures a secure fit while offering reliable performance

    This male disconnect terminal offers excellent holding force

    When crimped and shrunk, pre-insulated adhesive-lined polyolefin offers seal resistance to water and salt

    Mates with 0.25-in wide female tab

    Accommodates wire sizes 16 to 14 AWG

    Made of electrolytic copper for good conductivity and has corrosion-resistant tin plating

    Withstands a maximum temperature of 221 degrees F (105 degrees C)

    Rated 600V for building wire and 1000V for signs, fixtures or luminaires

    UL Listed, CSA Certified and RoHS 2011/65/EU Compliant

    250/case

3M™ Scotchlok™ Color-Coded Heat Shrink Male Disconnect Terminal allows for quick and easy disconnect. The butted-seam barrel is covered by an adhesive-lined polyolefin tubing to offer moisture-seal protection. It withstands a maximum temperature of 221 degrees F (105 degrees C). Its electrolytic copper construction offers good conductivity and a tin-plated finish resists corrosion.

3M™ Scotchlok™ Color-Coded Heat Shrink Male Disconnect Terminal attaches to the mating part with a tongue that slips over the female tab. This versatile terminal has a butted-seam barrel that is covered by a see-through, pre-insulated transparent tubing. The tubing provides seal resistance to water, salt and other contaminants when crimped and shrunk. The heat shrink tubing offers better pullout strength and strain relief when shrunk. UL Listed, CSA Certified and RoHS 2011/65/EU Compliant.


Product Details

General Information
Manufacturer
3M
Part Number
7100164279
Product Type
Crimp Terminals, Lugs & Wire Nuts
