3M Vinyl Insulated Butted Seam Fork Terminal, 31-8-P

by 3M
No reviews
Original price $105.99 - Original price $105.99
Original price
$105.99
$105.99 - $105.99
Current price $105.99
Free shipping
3M™ Fork Terminal has a wider tongue for use on free-standing studs. The terminal has a vinyl-insulated, butted-seam barrel and withstands temperatures of -40 to 221 degrees F (-40 to 105 degrees C). Electrolytic copper... Read more
This product is made to order. Please allow 5 days for production.

Overview

3M

3M Vinyl Insulated Butted Seam Fork Terminal, 31-8-P

3M™ Fork Terminal has a wider tongue for use on free-standing studs. The terminal has a vinyl-insulated, butted-seam barrel and withstands temperatures of -40 to 221 degrees F (-40 to 105 degrees C). Electrolytic copper construction offers good conductivity and a tin-plated finish resists corrosion.3M™ Standard Fork Terminal is color-coded for quick and easy identification of the wire size required. The butted-seam barrel is covered by a funnel-designed, rigid-molded, polyvinyl chloride sleeve to guide the wire into position while providing electrical contacts and mechanical stress relief at the point of insulation. The abrasion-resistant, flared, vinyl-sleeve insulation ensures easy crimping. UL Listed, CSA Certified and RoHS 2011/65/EU Compliant.

Product Details

General Information
Brand
3M™
Fork Type
Standard
Terminal Style
Standard
Country Of Origin
United States
Lead Time
5 days
California Residents
Dimensions and Specifications
Maximum Conductor Size (Imperial)
18 AWG
Maximum Conductor Size (Metric)
.0823 mm²
Minimum Conductor Size (Imperial)
22 AWG
Minimum Conductor Size (Metric)
0.326 mm²
Stud Diameter (Imperial)
0.164 in
Stud Diameter (Metric)
4.166 mm
Maximum Conductor Size Imperial
18 AWG
Maximum Conductor Size Metric
.0823 mm²
Minimum Conductor Size Imperial
22 AWG
Minimum Conductor Size Metric
0.326 mm²
Material and Composition
Insulation Material
Vinyl
