Athena Power AP-MFATX25P8 Flex ATX 250W, 80 PLUS Bronze, for Mini-ITX Servers

No reviews
Original price $86.99 - Original price $86.99
Original price
$86.99
$86.99 - $86.99
Current price $86.99
Free shipping
Athena Computer Power is proud to introduce FLEX ATX power supply series. With smaller computers in demand the FLEX form factor is becoming a necessity for Mini-ITX and 1UITX computers. Not only does the FLEX... Read more

Overview

Athena Power

Athena Power AP-MFATX25P8 Flex ATX 250W, 80 PLUS Bronze, for Mini-ITX Servers

Athena Computer Power is proud to introduce FLEX ATX power supply series. With smaller computers in demand the FLEX form factor is becoming a necessity for Mini-ITX and 1UITX computers. Not only does the FLEX hone 250 Watts of power in this compact PSU, but it also comes with additional features such as Active PFC and the Remote ON/OFF feature. A Perfect Fit Like its name the FLEX ATX is a compact and flexible Power Supply. Designed for 1UITX rackmounts, Mini-ITX chassis, or as a replacement PSU for IBM SurePOS, Shuttle XPC, and HP Pavillion systems. Can be used to build media servers, business server, and provide power for all types of kiosks. Smart Auto Fan Speed Controller Thermal fan speed control will detect the amount of heat generated by the computer. Using the speed controller to detect the heat levels, it will automatically adjust the fan speed accordingly and the need to worry about heat levels, of a PSU, becomes almost non-existent. 80PLUS Certification Saving energy has become an important factor when choosing the appropriate power supply. The FLEX 250W is one of the latest Flex ATX PSU’s that brandishes 80PLUS Bronze certification. Providing efficiency during max and low loads, this PSU lives up to the standards of today’s world.

Product Details

General Information
Manufacturer
Athena Power
Part Number
AP-MFATX25P8
Product Type
Power Supply
California Residents
Power Description
Input Voltage Type
AC
Input Voltage
88 ~ 264 Volts AC
Output Voltage
+5V@12A, +3.3V@12A, +12V1@14A, +12V2@14A, -12V@0.5A, -5V@0.5A, +5V_SB@2.5A
Output Power
220 Watts
Physical Characteristics
Height
1.59"
Width
3.2"
Weight (Approximate)
2 lbs
Interfaces Ports
Connectors
ATX Connector 24 (20+4) Pin x 1
EPS-12V 8 (4 + 4) Pin x 1
P4-12V 4 pin x 1
PCIE 6 Pin x 2
SATA 15 Pin x 3
Molex 4 Pin x 2
Floppy 4 Pin x 1
