Athena Power AP-P4ATX70FEP8 True Green/Active PFC EPS/ATX-12V 700W 80 PLUS BRONZE

Original price $149.99 - Original price $149.99
Original price
$149.99
$149.99 - $149.99
Current price $149.99
Free shipping
The AP-P4ATX70FEP8 is a powerful power supply that delivers 700 Watts of true power to meet today's high-end system standards. Aside from a low noise level, it also accompanies with the dual fans, heat resistant... Read more

Overview

Brand img

Athena Power AP-P4ATX70FEP8 True Green/Active PFC EPS/ATX-12V 700W 80 PLUS BRONZE

The AP-P4ATX70FEP8 is a powerful power supply that delivers 700 Watts of true power to meet today's high-end system standards. Aside from a low noise level, it also accompanies with the dual fans, heat resistant with smart temperature, and automatic fan speed control. AP-P4ATX70FEP8 supports Core 2 Dual & Quad Core Processors plus it's Nvidia SLI and Quad SLi compatible. Dual EPS-12V output supports the Intel Skulltrail platform systems. This 700W power is for new OEM PC and server assemblies, including MiniServers & rackmount servers also support both 20- or 24-pin ATX v.2.2 and EPS-12V Xeon motherboards. The package includes four PCI Express 6pin / 8pin connectors to support Multi-GPU graphic card, which supplies the power to advanced Graphics cards that require Dual 6pin or Dual 8pin. ACTIVE PFC Auto switch also comes as built-in feature, and this power supply also supports Intel® Skulltrail and Core i7 platform systems. Multiple Support Function Supporting ATX V2.3, EPS-12V Xeon, and i7 motherboards it also includes 4x PCI-E 6-pin connectors for advanced graphics cards running in quad SLI or Crossfire configurations. This PSU can be used for mini-servers, server assemblies, rackmount servers, and desktops. Active PFC and Full Range The Active PFC and Full Range functions provide a smarter PSU. They have the ability to automatically detect the differences between the amounts of Wattage needed to power up the system. With the automatic exact Wattage distribution, close scrutiny is not required to maintain the PSU. Dual Front Fan With its dual fan features located at the front of the power supply, the rear fan intakes the heat that is produced inside the server or system and pushes it through the front fan. This design allows the power supply to be able to take 100% of the heat that is generated by the interior system and pushes it out of the server/system. While some other PSU fans work differently, this dual fan design is targeted to maintain a reliable source of power and keeping the system cool. Some may second guess this dual fan feature due to increase noises volumes, but with its thermal fan speed control it will detect the amount of heat generated by the computer and spin accordingly. Smart Auto Fan Speed Controller The built-in thermal fan speed control detects the amount of heat generated by the computer and spin accordingly. Silence is Golden In order to actualize virtually silent purposes, Athena Computer Power’s engineers have designed a low ripple and noise feature as a built-in feature of the PSU.

Product Details

General Information
Manufacturer
Athena Power
Part Number
AP-P4ATX70FEP8
Product Type
Power Supply
Power Description
Input Voltage Type
AC
Input Voltage
88 ~ 264 Volts AC
Output Voltage
+5V@22A, +12V1@28A, +12V2@28A, -12V@1.0A, +3.3V@20A, +5V_SB@3.5A
Output Power
700 Watts
Physical Characteristics
Height
3.25"
Width
5.75"
Weight (Approximate)
8 lbs
Interfaces Ports
Connectors
ATX 24 (20+4) Pin x 1
P4-12V 4 Pin x 1
EPS 12V 8 Pin x 2
PCIE 6 Pin x 2
PCIE 6+2 Pin x 2
SATA 15 Pin x 6
Molex 4 Pin x 2
Floppy 4 Pin x 1
