Traditionally used in landline telephone applications, these IDC splice connectors can be used to splice, tap or repair damaged low voltage conductors in voice and data applications.
Used for repairing broken wires and for adding an additional wire to an existing circuit
Internal moisture-resistant sealant protects wires from corrosion (indoor/outdoor use)
Quick, easy one-step splicing – insert unstripped conductors, crimp with 33-719 tool
Designed for use with solid copper single-conductor wire, 22-26 AWG
Permanent connection- once crimped they cannot be reused
Maximum insulated O.D. of .060 in. (1.52 mm)
3-wire Red IDC tap splice jellybean connector
Unlike UR and UY butt splices, the UB tap splice enables tapping into without a line creating a disruption in service. No need to cut the wire which is being tapped. Feeds tap to 1 additional wire.
