Ideal BTC500-4 B-TAP Insulation Piercing Tap Connector, Main 500-2/0, Tap 4/0-4

by IDEAL
$91.99
Breakaway torque nut snaps off when UL torque requirements are met Second nut remains for easy connector removal Self-insulated housing eliminates the need for tape. Safely installs on energized systems Grease-filled end cap seals end... Read more

Overview

Brand img

Ideal BTC500-4 B-TAP Insulation Piercing Tap Connector, Main 500-2/0, Tap 4/0-4

Breakaway torque nut snaps off when UL torque requirements are met

Second nut remains for easy connector removal

Self-insulated housing eliminates the need for tape. Safely installs on energized systems

Grease-filled end cap seals end of conductor for superior weather protection

Grease-filled boots protect copper teeth from corrosion and prevent arcing

Hardened copper teeth pierce insulation and bite into conductors

Rated to 90°C and 600V

Can be used on Cu-Cu, Al-Al, Cu-Al, and Al-Cu when used in non-tension, insulated applications

Full line has wire range from #14 to 750 kcmil

Safe, dependable, and easy. No other connector offers as much as the B-TAP® Insulation Piercing Connector. B-TAP® connectors are great for a wide range of applications such as temporary circuits, emergency repairs, disconnect/reconnect, remodeling, maintenance and repair, street lighting, service entrance, risers in high-rise construction, commercial metering, transformers, secondary midspan tap, and much more.

Self-insulating and weather-proof, B-TAP® connectors are installed using only a standard box or socket wrench. A breakaway torque nut guarantees a perfect connection every time. The grease-filled rubber end caps provide superior water and corrosion resistance, while the insulation-piercing design eliminates downtime and power interruptions.

That translates into a 60% installed savings compared to split bolts. The exclusive breakaway torque nut simply snaps off when UL torque requirements are met. No more guesswork! B-TAP® connectors can be safely installed on energized systems, eliminating power interruptions and downtime.


Product Details

General Information
Manufacturer
IDEAL
Part Number
BTC500-4
Product Type
Tap Connector
Specifications
Color
Black / Blue
Material
Thermoplastic
Miscellaneous
What's Included
B-TAP Insulation Piercing Tap Connector, Main 500-2/0, Tap 4/0-4
Features
Self-insulated housing eliminates the need for tape, Grease-filled end cap seals end of conductor for superior weather protection, Grease-filled boots protect copper teeth from corrosion and prevent arcing
