Overview
NTE Electronics WH16-03-25 Hook Up Wire 300V 16 Gauge Stranded 25' Orange
- Hook-up Wire
- NTE Electronics
- WH16-03-25
Features
The WH16-03-25 from NTE Electronics is a stranded Hook-up Wire with 16AWG tin-plated copper conductor and a orange PVC insulation. The WH series hook-up wire is ideal for internal wiring of electrical and electronic equipment, panels, meters, computers, business machines, appliances, & control panels. Point-to-point wiring where 300V is required. 6 Amp Max.Product Details
General Information
Manufacturer
NTE Electronics
Part Number
WH16-03-25
Cable Type
Hook-Up Wire
Physical Characteristics
Wire Gauge
16 AWG
Length
25' (7.62m)
Jacket Color
Orange
Conductor Material
Tinned Copper
Insulation Material
Poly-Vinyl Chloride (PVC)
Jacket (Insulation) Thickness
1/64"
Conductor Strand
7 x 32
Specifications
Voltage Rating
300 V
Maximum Temperature
90° C
RoHS
Compliant
Ratings
UL Style 1007, UL VW-1, CSA TR-64-1569, OSHA Acceptable
Packaging
Spool
Weight (Approximate)
5 ounces
