Velleman MM100 FM/RDS Receiver Mini Module

Original price $18.00 - Original price $18.00
Original price
$18.00
$18.00 - $18.00
Current price $18.00
Free shipping
Small and functional FM receiver with access to an easy to use Arduino library! Features small size RDS/RBDS support volume control automatic frequency control automatic gain control connector pitch matches standard breadboard pitch line level... Read more

Overview

Brand img

Velleman MM100 FM/RDS Receiver Mini Module

Small and functional FM receiver with access to an easy to use Arduino library!

Features

  • small size
  • RDS/RBDS support
  • volume control
  • automatic frequency control
  • automatic gain control
  • connector pitch matches standard breadboard pitch
  • line level analog output
  • Arduino® library available

Specifications

  • interface: 2-wire or 3-wire
  • FM range: worldwide FM support
  • power/Logic level: 3.3 V
  • max. current: 20 mA
  • sensitivity: 1.7 µ Vemf
  • dimensions: 23 x 15 mm (ca. 0.9 x 0.59 inch)

Product Details

General Information
Manufacturer
Velleman
Part Number
MM100
Product Type
DIY Kit
