Velleman VMA321 1 A Lithium Battery Charging Board

Original price $9.00 - Original price $9.00
Original price
$9.00
$9.00 - $9.00
Current price $9.00
Free shipping
The TP4056 based VMA321 module is a complete constant-current/constant-voltage linear charger for single cell lithium-ion batteries. Specifications input voltage: 4.5 to 5.5 VDC (by on-board USB connector) charging current: 1 A adjustable charge accuracy: 1.5... Read more

Overview

Brand img

Velleman VMA321 1 A Lithium Battery Charging Board

The TP4056 based VMA321 module is a complete constant-current/constant-voltage linear charger for single cell lithium-ion batteries.

Specifications

  • input voltage: 4.5 to 5.5 VDC (by on-board USB connector)
  • charging current: 1 A adjustable
  • charge accuracy: 1.5 %
  • Full Charge Voltage: 4.2 V
  • Charge indicator: green = fully charged, red = charging
  • working temperature: 14 °F to +176°F (-10°C to +80°C)
  • weight: 0.35 oz. (10 g)
  • dimensions : 0.98" x 0.75" x 0.39" (25 x 19 x 10 mm)

Product Details

General Information
Manufacturer
Velleman
Part Number
VMA321
Product Type
Charging Board
